LFPP9 9,000lb 4-Post Parking Lift

Specifications:

Power – Volts 120,  HP 1.5,  Amp 15,  Ph 1,  Hz 60

Rise Time – 90s

Drop Time – 60s

9k 4 Post Parking



Post Dimensions – 7″ x 5″

Post Bases – 12″ x 10″

Approach Ramp Dimensions – 36″ x 18″

Drive Through Clearance – 81-3/4″

A – Clearance under runway at full height – 74″

B – Overall Height – 95″

C – Overall Length including Posts Bases – 180″

D – Pump sticks out 15″ from Post

E – Overall width including Posts Bases – 108″

F – Inner width inside Posts – 94.5″

G – Runway span – 76″

H – Runway width – 19″

I – Runway length – 164″

J – Inner length inside Posts – 162″

K – Approach Ramp Dimensions – 36″ x 18″

L – Post Dimensions – 7″ x 5″ Post Bases – 12″ x 10″



Shipping dimensions:

Lift 177” x 22” x 28” 1900lbs
Pump is wrapped up inside the lift and included in the Lift’s dimensions.
Optional Wheel Kit 40” x 24” x 10” 120lbs
Optional Rolling Jack 38” x 25” x 10” 300lbs
