Specifications:
- Capacity – 10,000lbs
- Rise Time – 90s
- Drop Time – 60s
- Power – 110V, 1PH, 20AMP
- Post Dimensions – 5″ x 6″
- Post Bases – 12″ x 12″
- Approach Ramp Dimensions – 37″ x 19.5″
Dimensions:
- A – Clearance under runway at full height – 77″
- B – Overall Height – 96″
- C – Overall Length including Posts Bases – 197.5″
- D – Pump sticks out 13″ from Post
- E – Overall width including Posts Bases – 126.5″
- F -Inner width inside Posts – 113″
- G – Runway span – 82.5″
- H – Runway width – 18.5″
- I – Runway length – 182″
- J – Inner length inside Posts – 179
